Łącznik prefabrykacyjny
Efektywność i opłacalność ekonomiczna montażu prefabrykatów żelbetowych jest obecnie znacznie większa. Łączniki prefabrykacyjne Halfen oferują optymalne rozwiązania dla każdego rodzaju prefabrykatów żelbetowych.
Łącznik prefabrykacyjny Halfen HEK3 jest innowacyjnym i wszechstronnym rozwiązaniem do szybkiego i łatwego łączenia prefabrykatów żelbetowych ze sobą lub z sąsiadującymi z nimi elementami wylewanymi na mokro.
obszary zastosowań
portfolio produktowe
Łącznik prefabrykacyjny HEK3
Łącznik prefabrykacyjny Halfen HEK3 jest innowacyjnym i wszechstronnym rozwiązaniem do szybkiego i łatwego łączenia prefabrykatów żelbetowych ze sobą lub z sąsiadującymi z nimi elementami wylewanymi na mokro. Kotwy tulejowe Halfen Demu, takie jak np. T-FIXX®, kotwy bolcowe czy prętowe przenoszą siły rozciągające i ścinające na prefabrykat. Atutem systemu jest szybki i efektywny montaż prefabrykatów betonowych. Połączenie może być obciążone natychmiast po zainstalowaniu. W rezultacie znacznie skraca się czas realizacji projektu.
korzyści
Łącznik prefabrykacyjny HEK3
- Przenoszenie sił rozciągających i ścinających
- Połączenie skręcane umożliwia łatwą, szybką i bezpieczną instalację na placu budowy
- Możliwość regulacji w razie ewentualnych niedokładności w montażu lub ustawieniu prefabrykatów
- Bez tymczasowych zamocowań
- Montaż niezależnie od warunków pogodowych
- Niższe koszty dzięki szybkiej instalacji
- Jeden typ łącznika do różnych zastosowań
- Brak konieczności stosowania specjalistycznych narzędzi
- Trwała ochrona antykorozyjna
- Kotwa tulejowa Halfen Demu jako element systemu z Europejską Aprobatą Techniczną i darmowe oprogramowanie obliczeniowe Halfen
dokumentacja technicznaDocumentazione tecnica
Tutaj znajdziesz wszystkie ważne informacje techniczne o produktach. Dokumenty te pomogą Ci w planowaniu, realizacji i weryfikacji, a także będą dostępne w każdej chwili w aktualnej i przejrzystej formie.
Software
Uwaga: Niektóre programy wymagają klucza rejestracyjnego. Po instalacji możesz go uzyskać bezpośrednio z poziomu oprogramowania lub za pośrednictwem menu „Rejestracja oprogramowania”, podając swój adres e-mail i klucz produktu.
Proszę zwrócić uwagę na gwarancję
HEK Łącznik prefabrykacyjny
HEK - 3.10
wymagania systemowe
Windows 8
Windows 10
Windows 11
leviat_software_hek.exe
exe / 69.26 MB
